1N5398 is an 800 Volt 1.5 Ampere Silicon Rectifier General Purpose Diode and its voltage range is up to 800 Volts.
1N5398 Features
- Low forward voltage drop
- High current capability
- High reliability
- High surge current capability
1N5398 Specification
| Mfr Package Description | ROHS COMPLIANT, PLASTIC PACKAGE-2 |
| Diode Type | RECTIFIER DIODE |
| Diode Element Material | SILICON |
| Forward Voltage-Max (VF) | 1.1 V |
| Non-rep Pk Forward Current-Max | 50.0 A |
| Operating Temperature-Min | -65.0 Cel |
| Operating Temperature-Max | 150.0 Cel |
| Output Current-Max | 1.5 A |
| Rep Pk Reverse Voltage-Max | 800.0 V |
| Reverse Current-Max | 5.0 µA |
You can download this datasheet for 1N5398 800V 1.5A General Purpose Diode from the link given below:
