2N6427 NPN Darlington Transistor is designed for applications requiring extremely high current gain at collector currents to 1.0 A
2N6427 Pinout
2N6427 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Base |
| 3 | Collector |
2N6427 Key Features
- High current (max. 500 mA)
- Low voltage (max. 30 V)
- High DC current gain (min. 10000)
2N6427 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 40 V |
| Collector-Base Voltage (Vcb) | 40 V |
| Emitter-Base Voltage (Veb) | 12 V |
| Collector Current (Ic) | 0.5 A |
| Collector Power Dissipation (Pc) | 0.625 W |
| Transition Frequency | 130 MHz |
Application
- General purpose
- High gain amplification
You can download this datasheet for 2N6427 NPN Darlington Transistor - Datasheet from the link given below:
