BAT42 series employs the Schottky Barrier principle in a large area metal−to−silicon power diode featuring very low turn-on voltage and fast switching. BAT42 has integrated protection against excessive voltage such as electrostatic discharges.
BAT42 Features
- Very low turn-on voltage
- Fast switching
BAT42 Specification
| Mfr Package Description | PLASTIC, DO-35, 2 PIN |
| Diode Type | RECTIFIER DIODE |
| Diode Element Material | SILICON |
| Output Current-Max | 0.2 A |
| Power Dissipation-Max | 0.2 W |
| Rep Pk Reverse Voltage-Max | 30.0 V |
| Reverse Recovery Time-Max | 0.005 µs |
You can download this datasheet for BAT42 Schottky Barrier Diode from the link given below:
