BT131 is a sensitive gate triac suitable for direct coupling to TTL, HTL, CMOS and application such as various logic functions, low power AC switching applications, such as fan speed, small light controllers and home appliance equipment.
BT131 Pinout
BT131 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Anode |
| 2 | Gate |
| 3 | Cathode |
BT131 Key Features
- With TO-92 package
- Glass passivated, sensitive gate triac in a plastic envelope
- These devices are intended to be interfaced directly to microcontrollers, logic integrated circuits and other low power gate trigger circuit
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
BT131 Specification
| Type | Vdsm (V) | It (A) | Igt (mA) | Vgt (V) |
|---|---|---|---|---|
| BT131 | 500 | 1.0 | 3.8 | 0.7 |
Application
- Motor Control
- Industrial and Domestic lighting
- Heating
- Static Switching
You can download this datasheet for BT131 1A 500V TRIAC - Datasheet from the link given below:
