LMC660 CMOS Quad Op-Amp comprises of four industry standard, high gain, frequency compensated, general purpose amplifiers for cost sensitive equipment. The op-amp is stable at unity gain and does not have a reverse phase in overdrive conditions. The IC is available in a 14-pin hermetically sealed dual in line IC packaging (DIP).
Operational Amplifier
Operational amplifiers are simple electronic circuits that can boost a weak signal to a level of higher amplitude. An operational amplifier is generally used in applications such as home entertainment systems, megaphones, speakers, and microphones, etc. An op-amp usually operates with a number of feedback components that determine the resulting function or “operation” of the amplifier and by virtue of the different feedback, configurations whether resistive, capacitive, or both.
LMC660 Pinout
LMC660 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | OUT A | Output Of Amplifier A |
| 2 | INV-INPUT A | Inverting Input Of Amplifier A |
| 3 | NON-INV-INPUT A | Non Inverting Input Of Amplifier A |
| 4 | V+ | Positive Power Supply |
| 5 | NON-INV-INPUT B | Non Inverting Input Of Amplifier B |
| 6 | INV-INPUT B | Inverting Input Of Amplifier B |
| 7 | OUT B | Output Of Amplifier B |
| 8 | OUT C | Output Of Amplifier C |
| 9 | INV-INPUT C | Inverting Input Of Amplifier C |
| 10 | NON-INV-INPUT C | Non Inverting Input Of Amplifier C |
| 11 | V- | Negative Power Supply |
| 12 | NON-INV-INPUT D | Non Inverting Input Of Amplifier D |
| 13 | INV-INPUT D | Inverting Input Of Amplifier D |
| 14 | OUT D | Output Of Amplifier D |
LMC660 Features
- Rail-to-rail output swing
- Specified for 2 kΩ and 600Ω loads
- High voltage gain: 126 dB
- Low input offset voltage: 3 mV
- Low offset voltage drift: 1.3 µV/˚C
- Ultra low input bias current: 2 fA
- Input common-mode range includes V−
- Operating range from +5V to +15V supply
- ISS = 375 µA/amplifier; independent of V+
- Low distortion: 0.01% at 10 kHz
- Slew rate: 1.1 V/µs
Application
- High-impedance buffer or preamplifier
- Precision current-to-voltage converter
- Long-term integrator
- Sample-and-Hold circuit
- Peak detector
- Medical instrumentation
- Industrial controls
- Automotive sensors
LMC660 Datasheet
You can download this datasheet for LMC660 CMOS Quad Op-Amp from the link given below:
