MJE15029 PNP is Complementary Silicon Plastic Power Transistor. These devices are designed for use as high-frequency drivers in audio amplifiers
MJE15029 Pinout
MJE15029 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Base |
| 2 | Collector |
| 3 | Emitter |
| 4 | Case (Collector) |
MJE15029 Key Features
- Collector-Emitter Sustaining Voltage- : VCEO(SUS)= 120V(Min)
- High Current Gain-Bandwidth Product- : fT= 30MHz(Min)@ IC= -0.5A
- DC current gain -
- : hFE = 40 (Min) @IC= -3.0 A
- : hFE = 20 (Min) @IC= -4.0
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
- Type Designator: MJE15029
- Material of Transistor: Si
- Polarity: PNP
MJE15029 Specification
| Ic (mA) | Pd | Vce (max) | Vcb | hfe | @Ic | Ft |
|---|---|---|---|---|---|---|
| 8 | 50 | 120 | 120 | 40 | 100 | 30 |
MJE15029 Equivalent/Alternate:
MJE1100, MJE1101, MJE1102, MJE1103, MJE1123, MJE15028
Application
- Audio Amplifier
