The RHRP860 is hyper fast diodes with soft recovery characteristics. It has half the recovery time of ultrafast diodes and are silicon nitride passivated ion-implanted epitaxial planar construction.
RHRP860 Pinout
RHRP860 Features
- Hyper fast with Soft Recovery. . .. . <30ns
- Operating Temperature . . . . 175oC
- Reverse Voltage Up To. . .. . 600V
- Avalanche Energy Rated
- Planar Construction
Specification
| Diode Type | Rectifier Diode |
| Application | Hyperfast Soft Recovery |
| Diode Element Material | Silicon |
| Forward Voltage-Max (VF) | 2.1 V |
| Non-rep Pk Forward Current-Max | 100.0 A |
| Operating Temperature-Min | -65.0 Cel |
| Operating Temperature-Max | 175.0 Cel |
| Output Current-Max | 8.0 A |
| Power Dissipation-Max | 75.0 W |
| Rep Pk Reverse Voltage-Max | 600.0 V |
| Reverse Current-Max | 100.0 µA |
| Reverse Recovery Time-Max | 0.035 µs |
Application
- Switching Power Supplies
- Power Switching Circuits
- General Purpose
You can download this datasheet for RHRP860 8A 600V Hyper fast Diode from the link given below:
