The TDA1170 is a monolithic integrated circuit in a 12-lead quad in-line plastic package. It is intended for use in black and white and color TV receivers.
TDA1170 Pinout
TDA1170 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | RAMP OUT | Ramp Output Pin |
| 2 | VCC | Supply Voltage Pin |
| 3 | FLYBACK | Flyback Pin |
| 4 | GND | Ground Pin |
| 5 | GND | Ground Pin |
| 6 | POWER AMP: OUT | Power Amplifier Output Pin |
| 7 | POWER AMP: SUPPLY VOLTAGE | Power Amplifier Supply Voltage Pin |
| 8 | REG: VOLTAGE | Regulated Voltage Pin |
| 9 | HEIGHT ADJUST: | Height Adjustment Pin |
| 10 | SYNC: IN | Synchronous Input Pin |
| 11 | OSC | Oscillator Pin |
| 12 | GND | Ground Pin |
| 13 | GND | Ground Pin |
| 14 | AMP: IN | Amplifier Input Pin |
| 15 | COMP: | Compensation Pin |
| 16 | RAMP GENER: | Ramp Generator Pin |
TDA1170 Features
- Vertical Oscillator
- Voltage Ramp Generator
- High Gain Power Amplifier
- Fly Back Generator
You can download this datasheet for TDA1170 TV Vertical Deflection System – Datasheet from the link given below:
