In this project
TLE2071 is a Low Noise High-Speed JFET Input Op-Amp. The BiFET operational amplifiers offer the inherently higher input impedance of the JFET-input transistors, without sacrificing the output drive associated with bipolar amplifiers. This makes this IC better suited for interfacing with high-impedance sensors or very low-level ac signals. The IC has a range of working conditions a wide range of working voltages and possesses direct interfacing capability with almost every PMOS, CMOS, and NMOS device. Moreover, the IC offers a wide array of features such as high noise immunity, ESD barring/reduction, and exceptionally low power dissipation.
Operational Amplifier
An operational amplifier is one of the basic building blocks for analog circuits, An operational amplifier takes in differential voltage input and produces a single-ended voltage output. The basic purpose of employing an operational amplifier in an analog circuit is to perform the function of signal amplification: The process of boosting an electrical signal of low strength to a level of higher amplitude. Op-amps also function as a filter of the input signal; meaning that, an operational amplifier is able to extract the signal with the target frequency. Op-amps can be divided into two fundamental parts:
- Precision Op-amps
- Differential Op-amps
TLE2071 Pinout
TLE2071 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | OFFSET N1 | Offset Null Pin 1 |
| 2 | INV-INPUT | Inverting Input Of Amplifier |
| 3 | NON-INV-INPUT | Non Inverting Input Of Amplifier |
| 4 | VCC- | Negative Supply Voltage |
| 5 | OFFSET N2 | Offset Null Pin 2 |
| 6 | OUT | Output Of Amplifier |
| 7 | VCC+ | Positive Supply Voltage |
| 8 | NC | No Connection |
TLE2071 Features
- Greater Than 2× Bandwidth (10 MHz) and 3× Slew Rate (45 V/µs) Than TL07x
- Ensured Maximum Noise Floor 17 nV/
- On-Chip Offset Voltage Trimming for Improved DC Performance
- Wider Supply Rails Increase Dynamic Signal Range to
Application
- Video and Imaging
- Automotive and Transportation
- Communications and Telecom
- Computers and Peripherals
- Consumer Electronics
- Energy and Lighting
- Industrial
- Space, Avionics and Defense
- Security
TLE2071 Datasheet
You can download this datasheet for TLE2071 Low Noise High Speed JFET Input Op-Amp from the link given below:
