ULN2064B is designed to interface logic to a wide variety of high current, high voltage loads, this device contains four NPN Darlington switches delivering up to 1.5A with a specified minimum breakdown of 50V and a sustaining voltage of 35V measured at 100 mA.
The ULN2064B contains integral suppression diodes for inductive loads that have common emitters. The ULN2064B feature isolated Darlington pinouts and is intended for applications such as emitter follower configurations. The input of the ULN2064B is compatible with popular 5V logic families.
ULN2064 Pinout
ULN2064 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | K | Output Pin K |
| 2 | C | Input Pin C |
| 3 | B | Input Pin B |
| 4 | GND | Ground Pin |
| 5 | GND | Ground Pin |
| 6 | B | Input Pin B |
| 7 | C | Input Pin E |
| 8 | K | Output Pin K |
| 9 | C | Output Pin C |
| 10 | NC | No Connection |
| 11 | B | Input Pin B |
| 12 | GND | Ground Pin |
| 13 | GND | Ground Pin |
| 14 | B | Input Pin B |
| 15 | NC | No Connection |
| 16 | C | Output Pin C |
ULN2064B Features
- Output current to 1.5 A for each Darlington
- Minimum breakdown 50 V
- Sustaining voltage at least 35 V
- Integral suppression diodes (ULN2064B, ULN2066B and ULN2068B
- Isolated Darlington pinout (ULN2074B)
- Versions compatible with all popular logic families
Application
- Emitter follower configurations.
You can download this datasheet for ULN2064B Hi-Voltage Hi-Current Darlington Switches – Datasheet from the link given below:
