2N6388 is a silicon Epitaxial-Base NPN power transistor in a monolithic Darlington configuration mounted in Jedec TO-220 plastic package. It is intended for use in low and medium-frequency power applications.
What is Darlington Transistor?
A Darlington transistor is also known as a Darlington pair is an electronics component made via the combination of two PNP or NPN BJTs (Bipolar Junction Transistor) connected in such a way that it allows a very high amount of current gain. Darlington pair is simply used in many applications where switching or amplification is crucial.
2N6388 Pinout
2N6388 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Base |
| 2 | Collector |
| 3 | Emitter |
| 4 | Collector (Case) |
2N6388 Key Features
- High DC Current Gain
- Low Collector Saturation Voltage
- Npn Darlington
- High Current Capability
- Collector–Emitter Sustaining Voltage – @ 100 mAdc
- VCEO(sus) = 80 Vdc (Min) — 2N63
- Type Designator: 2N6388
- Material of Transistor: Si
- Polarity: NPN
Specification
| Ic (mA) | Pd (mW) | Vce (max) | Vcb | hfe | @Ic | FT (MHz) |
|---|---|---|---|---|---|---|
| 10 | 65 | 80 | 80 | 1000-20,000 | 5000 | 20 |
2N6388 Equivalent/Alternate:
- 2N60, 2N600, 2N6000, 2N6001, 2N6002, 2N6666/6667/6668
Application
- low and medium frequency power
- low speed switching
You can download this datasheet for2N6388 NPN Power Darlington Transistor from the link given below:
