2SA715 PNP General Purpose Transistor is designed for Low-frequency power amplifier and complementary pair with 2SC1162.
2SA715 Pinout
2SA715 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
2SA715 Key Features
- Good Linearity of hFE
- Collector-Emitter Breakdown Voltage- V(BR)CEO= -35V (Min)
- Complement to Type 2SC1162
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
2SA715 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 35 V |
| Collector-Base Voltage (Vcb) | 35 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 2.5 A |
| Collector Power Dissipation (Pc) | 10 W |
| Transition Frequency | 160 MHz |
Application
- Designed for use in low frequency power amplifier applications.
You can download this datasheet for 2SA715 PNP General Purpose Transistor – Datasheet from the link given below:
