The 74LS795 IC is a part of the 74XXYY IC series. The 74LS795 is a Buffer IC that is specifically designed to improve both the performance & density of 3-State memory address driver, clock drivers & bus oriented receivers & drivers. 74LS795 IC has a wide range of working voltage, a wide range of working conditions, and directly interfaces with CMOS, NMOS, and TTL. The output of the IC always comes in TTL which makes it easy to work with other TTL devices and microcontrollers. The IC 74LS795 is smaller in size and it has a much faster speed which makes it reliable in every kind of device.
What is a Buffer?
Buffers are generally used to increase the propagation delay of circuits by driving the large capacitive loads. A buffer is a basic logic gate that passes its input, unchanged, to its output. Its behavior is the opposite of a NOT gate. The main purpose of a buffer is to regenerate the input, usually using a strong high and a strong low.
74LS795 Key Features & Specifications
- Technology Family: LS
- VCC (Min) (V): 4.75
- VCC (Max) (V): 5.25
- Channels (#): 8
- IOL (Max) (mA): 24
- ICC (Max) (uA): 52000
- IOH (Max) (mA): -15
- Input type: Bipolar
- Output type: 3-State
- Propagation speed: (tpd 10-50ns)
- PNP Inputs Reduce Loading
- 3-State Outputs Drive Bus Lines
- Input Clamp Diodes Limit High-Speed Termination Effects
- Data rate (Mbps): 70
- Rating Catalog
74LS795 Pinout
| Pin No. | Pin Name | Description |
|---|---|---|
| 1 | G1′ | Active Low Enable Input G1′ |
| 2 | A1 | Data Input Pin A1 |
| 3 | Y1 | Data Output Pin Y1 |
| 4 | A2 | Data Input Pin A2 |
| 5 | Y2 | Data Output Pin Y2 |
| 6 | A3 | Data Input Pin A3 |
| 7 | Y3 | Data Output Pin Y3 |
| 8 | A4 | Data Input Pin A4 |
| 9 | Y4 | Data Output Pin Y4 |
| 10 | GND | Ground Pin |
| 11 | Y5 | Data Output Pin Y5 |
| 12 | A5 | Data Input Pin A5 |
| 13 | Y6 | Data Output Pin Y6 |
| 14 | A6 | Data Input Pin A6 |
| 15 | Y7 | Data Output Pin Y7 |
| 16 | A7 | Data Input Pin A7 |
| 17 | Y8 | Data Output Pin Y8 |
| 18 | A8 | Data Input Pin A8 |
| 19 | G2′ | Active Low Enable Input G2′ |
| 20 | VCC | Chip Supply Voltage |
Applications
The 74LS795 has a wide variety of applications, a few of them are mentioned down below:
- Usually function as Clamping diodes at system inputs to simplify system design.
74LS795 Datasheet
You can download the datasheet for 74LS795 8-Bit Tri-State Octal Buffer IC from the link given below:
