The T8A820M is a monolithic integrated audio amplifier in an 8 lead dual-in-line plastic package. It is intended for use as a frequency class B power amplifier With a Wide range Of supply volt- 3 to 16V, in portable radios, cassette recorders, and players, etc. The main features are minimum Working supply voltage of a low quiescent number of external components. good ripple rejection, no Cross-over distortion, IOW power dissipation
TBA820M Pinout
TBA820M Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | FREQUENCY COMPENSATION | Frequency Compensation Pin |
| 2 | GAIN SETTING | Gain Setting Pin |
| 3 | IN | Input Pin |
| 4 | GND | Ground Pin |
| 5 | OUTPUT | Output Pin |
| 6 | Supply Voltage | Supply Voltage Pin |
| 7 | BOOTSTRAP | Bootstrap Pin |
| 8 | RIPPLE REJECTION | Ripple Rejection Pin |
You can download this datasheet for TBA820M Audio High Power Amplifier – Datasheet from the link given below:
