TL064 Low-Power JFET Input Op-Amp – Datasheet

by
6,673 views
TL064 Datasheet
Contents hide
1 Operational Amplifier
2 TL064 Pinout
3 TL064 Features
4 Application
5 TL064 Datasheet

TL064 operational amplifiers are designed using the JFET (junction field-effect transistor) technology. The IC has a range of working conditions a wide range of working voltages and possesses direct interfacing capability with almost every PMOS, CMOS, and NMOS device. Moreover, the IC offers a wide array of features such as high noise immunity, ESD barring/reduction, and exceptionally low power dissipation.

Buy now

Operational Amplifier

Operational Amplifiers are basically voltage amplifying devices designed to be used with components like capacitors and resistors. They serve as the core part of any analog device. Feedback components like capacitors and resistors are used to determine the operation of the amplifier. The amplifier can perform many different operations (resistive, capacitive, or both), giving it the name Operational Amplifier. Op-amps are linear devices that are ideal for DC amplification and are used often in signal conditioning, filtering or other mathematical operations

TL064 Pinout

TL064 Pin Configuration

Pin NoPin NameDescription
1OUTPUT 1Output Of Amplifier 1
2INV-INPUT 1Inverting Input Of Amplifier 1
3NON-INV-INPUT 1Non Inverting Input Of Amplifier 1
4VCCCollector Supply Voltage
5NON-INV-INPUT 2Non Inverting Input Of Amplifier 2
6INV-INPUT 2Inverting Input Of Amplifier 2
7OUTPUT 2Output Of Amplifier 2
8OUTPUT 3Output Of Amplifier 3
9INV-INPUT 3Inverting Input Of Amplifier 3
10NON-INV-INPUT 3Non Inverting Input Of Amplifier 3
11VEEEmitter Supply Voltage
12NON-INV-INPUT 4Non Inverting Input Of Amplifier 4
13INV-INPUT 4Inverting Input Of Amplifier 4
14OUTPUT 4Output Of Amplifier 4

TL064 Features

  • Low Supply Current: 200 µA/Amplifier
  • High Slew Rate: 6.0 V/µs
  • Low Input Bias Current: 5.0 pA
  • High Gain Bandwidth: 2.0 MHz
  • High Input Impedance: 1012 Ω
  • Large Output Voltage Swing: ±14 V
  • Output Short Circuit Protection

Application

  • Tablets
  • White goods
  • Personal electronics
  • Computers

TL064 Datasheet

You can download this datasheet for L064 Low-Power JFET Input Op-Amp from the link given below:

Download Datasheet
