2SA933 is PNP General Purpose Transistor having linear Hybrid parameter forward current gain (hfe). 2SA933 is complementary to 2SC2412K.
2SA933 Pinout
2SA933 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
2SA933 Key Features
- Excellent hFE linearity.
- Complements the 2SC2412K / 2SC4081 / 2SC4617 / 2SC5658 /2SC1740S
2SA933 Specification
| Name | Description |
|---|---|
| Collector-Base Voltage (Vcb) | 50 V |
| Emitter-Base Voltage (Veb) | 5 V |
| Collector Current (Ic) | 0.1 A |
| Collector Power Dissipation (Pc) | 0.3 W |
| Transition Frequency | 140 MHz |
You can download this datasheet for 2SA933 PNP General Purpose Transistor – Datasheet from the link given below:
