The BD236 is silicon epitaxial-base NPN power transistors in Jedec SOT-32 plastic package intended for use in medium power linear and switching applications
Power Transistor?
Transistors are three-terminal semiconductor electronic devices that can be used as switches or amplifiers. They can be of NPN or PNP polarity, and many different types are available with different power and switching speed ratings. If a transistor designed to these concepts can handle more than 1 A of collector current, it is generally considered to be a power transistor. Such transistors must have low output resistance to deliver large load currents, and good junction insulation to resist high voltages. They must also dissipate heat very quickly to avoid overheating.
BD236 Pinout
BD236 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
BD236 Key Features
- DC Current Gain-
- : hFE= 40(Min)@ IC= -0.15A
- Minimum Lot-to-Lot variations for robust device performance and reliable operation
- Type Designator: BD236
- Material of Transistor: Si
- Polarity: PNP
- Maximum Emitter-Base Voltage |Veb|: 5 V
BD236 Specification
| Ic (mA) | Vce (max) | Vcb | hfe | @Ic | FT |
|---|---|---|---|---|---|
| 2 | 60 | 60 | 40 | 150 | 3 |
BD236 Equivalent/Alternate:
- BD201, BD202, BD203, BD204, BD235
Application
- Medium Power Linear switching
- General Purpose
- Audio Amplifiers
- Drivers
You can download this datasheet for BD236 PNP Power Transistor from the link given below:
