IRF730 5.5A 400V N-Channel Power MOSFET – Datasheet

3,214 views

IRF730 5.5A 400V N-Channel power MOSFET is designed using the company’s consolidated strip layout-based MESH OVERLAY process. This technology matches and improves the performances compared with standard parts from various sources.

IRF730 Pinout

IRF730 Pin Configuration

Pin NoPin Name
1Gate
2Drain
3Source

IRF730 Key Features

  • Repetitive Avalanche Rated
  • Fast switching
  • High thermal cycling performance
  • Low thermal resistance
  • Type Designator: IRF730
  • Type of Transistor: MOSFET
  • Type of Control Channel: N -Channel

IRF730 Specification

Id (A)Pd (W)Vds (max)Rds (on)Vgs (max)
5.5100400120

IRF730 Equivalent/Alternative

  • IRF034, IRF044, IRF044SMD, IRF054, IRF054SMD, IRF100B201

Application

  • Switched Mode Power Supplies
  • T.V. And Computer Monitor Power Supplies
  • D.C to D.C Converters
  • Motor Control Circuits
  • General Purpose Switching

You can download this datasheet for IRF730 5.5A 400V N-Channel Power MOSFET from the link given below:
