IRFP9240 12A 200V P-Channel Power MOSFETs from Vishay provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-247 package is preferred for commercial-industrial applications where higher power levels preclude the use of TO-220 devices. The TO-247 is similar but superior to the earlier TO-218 package because of its isolated mounting hole. It also provides greater creepage distance between pins to meet the requirements of most safety specifications
IRFP9240 Pinout
IRFP9240 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Gate |
| 2 | Drain |
| 3 | Source |
IRFP9240 Key Features
- Dynamic dv\dt Rating
- Repetitive Avalanche Rated
- P-Channe1
- Isolated Central Mounting Hole
- Fast Switching
- Ease of Paralleling
- Simple Drive Requirements
- Type Designator: IRFP9240
- Type of Transistor: MOSFET
- Type of Control Channel: P -Channel
IRFP9240 Specification
| Id (A) | Pd (W) | Vds (max) | Rds (on) | Vgs (max) |
|---|---|---|---|---|
| 11 | 125 | 200 | 0.5 | 20 |
IRFP9240 Equivalent/Alternative
- IRF034, IRF044, IRF044SMD, IRF054, IRF054SMD, IRF100B201
Application
- Commercial-Industrial Applications
You can download this datasheet for IRFP9240 12A 200V P-Channel Power MOSFET from the link given below:
