The LM380 is a power audio amplifier for consumer applications. In order to hold system cost to a minimum, the gain is internally fixed at 34 dB. A unique input stage allows inputs to be ground referenced. The output is automatically self-centering to one-half the supply voltage. The package outline is standard dual-in-line. This makes the device easy to use in a standard p-c layout. Uses include simple phonograph amplifiers, intercoms, line drivers, teaching machine outputs, alarms, ultrasonic drivers, TV sound systems, AM-FM radio, small servo drivers, power converters, etc.
LM380 Pinout
LM380 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | BYPASS | Bypass Pin |
| 2 | NON-INV-IN | Non-Inverting Input Pin |
| 3 | GND | Ground Pin |
| 4 | GND | Ground Pin |
| 5 | GND | Ground Pin |
| 6 | INV-IN | Inverting Input Pin |
| 7 | GND | Ground Pin |
| 8 | Vout | Supply Voltage Output Pin |
| 9 | NC | No Connection |
| 10 | GND | Ground Pin |
| 11 | GND | Ground Pin |
| 12 | GND | Ground Pin |
| 13 | NC | No Connection |
| 14 | Vs | Supply Voltage |
LM380 Key Features
- Wide supply voltage range
- Low quiescent power drain
- Voltage gain fixed at 50
- High peak current capability
- Input referenced to GND
- High input impedance
- Low distortion
- The quiescent output voltage is at one-half of the supply voltage
- Standard dual-in-line package
Application
- phonograph amplifiers
- Intercoms
- Line drivers
- Teaching machine outputs
- Alarms
- Ultrasonic drivers
- TV sound systems
- AM-FM radio
- Small servo drivers
- Power converters
You can download this datasheet for LM380 2W Audio Power Amplifier – Datasheet from the link given below:
