LM6134 comprises of four high gain, independent, industry standard, Low Power 10 MHz Rail-to-Rail I/O Operational Amplifier. The IC holds compatibility with almost every CMOS, NMOS, and PMOS device. The IC is always available in a 14 – pin dual in line IC packaging (DIP). The IC holds great importance in applications requiring high gain precision and noise cancellation.
Operational Amplifier
An operational amplifier is a simple electronic configuration that has the capability of boosting an electrical signal of lower amplitude to a higher level. operational amplifiers are used in nearly every electronic application, whether it be consumer electronic products such as mobile phones, laptops, PCs, etc; or robust electronic instrumentation equipment used in the process control industry.
LM6134 Pinout
LM6134 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | OUT A | Output Pin Of Amplifier A |
| 2 | INV-INPUT A | Inverting Input Of Amplifier A |
| 3 | NON-INV-INPUT A | Non Inverting Input Of Amplifier A |
| 4 | V+ | Positive Power Supply |
| 5 | NON-INV-INPUT B | Non Inverting Input Of Amplifier B |
| 6 | INV-INPUT B | Inverting Input Of Amplifier B |
| 7 | OUT B | Output Pin Of Amplifier B |
| 8 | OUT C | Output Pin Of Amplifier C |
| 9 | INV-INPUT C | Inverting Input Of Amplifier C |
| 10 | NON-INV-INPUT C | Non Inverting Input Of Amplifier C |
| 11 | V- | Negative Power Supply |
| 12 | NON-INV-INPUT D | Non Inverting Input Of Amplifier D |
| 13 | INV-INPUT D | Inverting Input Of Amplifier D |
| 14 | OUT D | Output Pin Of Amplifier D |
LM6134 Features
- Rail-to-Rail input CMVR −0.25V to 5.25V
- Rail-to-Rail output swing 0.01V to 4.99V
- High gain-bandwidth, 10 MHz at 20 kHz
- Slew rate 12 V/µs
- Low supply current 360 µA/Amp
- Wide supply range 2.7V to over 24V
- CMRR 100 dB
- Gain 100 dB with RL = 10k
- PSRR 82 dB
Application
- Battery operated instrumentation
- Instrumentation Amplifiers
- Portable scanners
- Wireless communications
- Flat-panel display driver
LM6134 Datasheet
You can download this datasheet for LM6134 Low Power 10MHz Quad Operational Amplifier from the link given below:
