OP307GP is a Low-Noise High-Speed Precision Op-amp IC. OP37 operational amplifiers combine outstanding noise performance with excellent precision and high-speed specifications. The wideband noise is only 3 nV//Hz and with the 1/f noise corner at 2.7 Hz, low noise is maintained for all low-frequency applications. The IC is always available in an 8 – pin hermetically sealed dual in line IC Packaging (DIP), and is compatible with almost every PMOS, NMOS, and CMOS device. OP37GP offers a wide variety of features such as ESD protection and low power dissipation.
Precision Operational Amplifier
Precison amplifiers, in terms of operation are similar to normal operational amplifiers. Precision op-amps have better design specifications. They are primarily used between sensors such as strain gages, ultrasonic piezoelectric transducers, and photodetectors to capture their output signals without loading the fragile transducer output. They are also widely used in automotive industry: to monitor the myriad sensors in cars and manufacturing facilities.
OP37 Pinout
OP37 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | VIO TRIM 1 | Input offset voltage TRIM 1 |
| 2 | INV-INPUT | Inverting Input Voltage Of Amplifier |
| 3 | NON-INV-INPUT | Non Inverting Input Voltage Of Amplifier |
| 4 | VCC- | Negative Power Supply |
| 5 | NC | No Connection |
| 6 | OUT | Output Of Amplifier |
| 7 | VCC+ | Positive Power Supply |
| 8 | VIO TRIM 2 | Input offset voltage TRIM 2 |
OP37 Features
- Very Low Peak-to-Peak Noise Voltage at 0.1 Hz to 10 Hz 80 nV Typ
- Low Input Offset Voltage 25 µV Max
- High Voltage Amplification 1 V/µV Min
- Minimum Slew Rate 11 V/µ
Application
- Low Noise DC Amplifiers
- Microphone Amplifiers
- Precision Amplifiers
- Tape-Head Preamplifiers
- Thermocouple Amplifiers
- Low-LeveI Signal Processing
- Medical Instrumentation
- Strain-Gauge Amplifiers
- High Accuracy Data Acquisition
OP37GP Datasheet
You can download this datasheet for OP37GP Precision Op-Amp from the link given below:
