2N6426 NPN Darlington Transistor is designed for applications requiring extremely high current gain at currents to 1.0 A
2N6426 Pinout
2N6426 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Base |
| 3 | Collector |
2N6426 Specification
| Name | Description |
|---|---|
| Collector-Emitter Voltage (Vce) | 40 V |
| Collector-Base Voltage (Vcb) | 40 V |
| Emitter-Base Voltage (Veb) | 12 V |
| Collector Current (Ic) | 0.5 A |
| Collector Power Dissipation (Pc) | 0.625 W |
| Transition Frequency | 150 MHz |
Application
- Extremely high current gain at currents to 1.0 A
You can download this datasheet for 2N6426 NPN Darlington Transistor – Datasheet from the link given below:
