BAS45A is 125 Volt 0.25 Ampere Low Epitaxial medium-speed switching diode with a low leakage current in a hermetically-sealed glass SOD68 (DO-34) package.
BAS45A Features
- Continuous reverse voltage :max. 125 V
- Repetitive peak forward current :max. 625 mA
- Low reverse current: max. 1nA
- Switching time: typ. 1.5μs.
BAS45A Specification
| Mfr Package Description | HERMETIC SEALED, GLASS PACKAGE-2 |
| Diode Type | RECTIFIER DIODE |
| Diode Element Material | SILICON |
| Forward Voltage-Max (VF) | 1.0 V |
| Non-rep Pk Forward Current-Max | 4.0 A |
| Operating Temperature-Max | 175.0 Cel |
| Output Current-Max | 0.25 A |
| Peak Reflow Temperature (Cel) | 260 |
| Power Dissipation-Max | 0.3 W |
| Rep Pk Reverse Voltage-Max | 125.0 V |
| Reverse Recovery Time-Max | 1.5 µs |
| Time Peak Reflow Temperature-Max (s) | 30 |
Application
- Low leakage current applications.
You can download this datasheet for BAS45A 125V 0.25A Low Leakage Diode from the link given below:
