BC547 NPN Transistor – Datasheet

22,666 views

BC547 is an NPN epitaxial silicon transistor. It is mostly used for current amplification and switching. It has three terminals namely emitter, base, and collector. The amount of current flowing from base to the emitter controls the amount of the current flowing through the collector. BC547 has a gain value of 110 to 800.

For the transistor in the saturation region, the maximum collector current is 100mA when the base current is limited to 5mA. Typically voltages allowed across the collector-emitter(VCE) are 200mV and across base-emitter(VBE) is 900mV. For the transistor in the cutoff region, the voltage across base-emitter(VBE) is around 660mV.

bc547 npn transistor

BC547 NPN Transistor Pinout

PIN NUMBERPIN NAME
1Collector
2Base
3Emitter
bc547 transistor pinout

Features and specifications:

  • Transistor type: Bi-Polar NPN Transistor
  • DC Current Gain (hFE): 110-800
  • Collector current (IC):100mA
  • Collector Base Voltage (VCB): 50 V
  • Collector-Emitter voltage (VCE) : 45V
  • Emitter Base Voltage (VEB): 6V
  • Maximum Power dissipation: 500mW
  • Junction temperature: 150⁰C
  • Current gain-bandwidth product: 300MHz
  • Noise figure: 10 dB
  • Available in TO-92 Package

Applications and uses:

  • Current amplification
  • Switch
  • Pulse width modulation
  • Darlington pair
  • Driver module
