CD4027 belongs to the CD4XXX IC series. The IC is constructed by using the monolithic complementary MOS (CMOS), integrated with p-type and n-type enhancement mode transistors. Each flip-flop has independent J, K, set, reset, and clock inputs and buffered Q and Q outputs. These flip-flops are edge sensitive to the clock input and change state on the positive-going transition of the clock pulses. Set or reset is independent of the clock and is accomplished by a high level on the respective input. The output of the IC always comes in TTL and is directly interfaceable with other TTL, CMOS, and NMOS devices. The IC offers many features such as high noise immunity and low thermal dissipation. All inputs are protected against damage due to static discharge by diode clamps to VDD and VSS.

Buy Now

What is a JK Flip-Flop?

The JK Flip Flop is basically a gated RS flip flop with the addition of the clock input circuitry. When both the inputs S and R are equal to logic “1”, the invalid condition takes place. Thus to prevent this invalid condition, a clock circuit is introduced. The JK Flip Flop has four possible input combinations because of the addition of the clocked input. The four inputs are “logic 1”, ‘logic 0”. “No change’ and “Toggle”.

CD4027 Key Features

Wide supply voltage range 3.0V to 15V
High noise immunity 0.45 VDD (typ.)
Low power TTL compatibility Fan out of 2 driving 74L or 1 driving 74LS
Low power 50 nW (typ.)
Medium speed operation 12 MHz (typ.) with 10V supply

CD4027 Pinout

Pin No	Pin Name	Description
1	Q2	output 0f flip flop 2
2	Q2′	complement output 0f flip flop 2
3	CLK 2	clock 2 signal
4	R2	reset 2 value
5	K2	input 1 of flip flop 2
6	J2	input 2 of flip flop 2
7	SET 2	set value 2 signal
8	VSS	source supply
9	SET 1	set value 1 signal
10	J1	input 1 of flip flop 1
11	K1	input 2 of flip flop 1
12	R1	reset 1 value
13	CLK 1	clock 1 signal value
14	Q1′	complement output 0f flip flop 1
15	Q1	output 0f flip flop 1
16	VDD	Drain supply
