The LM733 IC is a two-stage, differential input, differential output, wide-band differential amplifier. LM733 is specified for operation over the 55C to 125C military temperature range. The IC is especially suited for low level instrumentation applications over a wide supply voltage range. The IC is available in an 8 – pin hermetically sealed dual in line IC packaging (DIP). The IC has a wide variety of working conditions, a wide range of working voltages, and is compatible with almost every known CMOS, NMOS, and PMS device.
Differential Operational Amplifier
A differential amplifier or a difference amplifier is a kind of electronic amplifier, that has the ability to amplify the difference between any two input voltage signals applied on the amplifier. Differential amplifiers also posses the inherent capability of suppressing any voltage common to the two inputs, such as a noise signal. A differential amplifier can be mathematically represented as:
Where,
- V0 is the output voltage
- V1 and V2 are the input voltage signals
- Ad is the gain of the amplifier
LM733 Pinout
LM733 Pin Configuration
| Pin No | Pin Name | Description |
|---|---|---|
| 1 | IN 2 | Input Pin 2 Of Amplifier |
| 2 | NC | No Connection |
| 3 | G2B | Gain Selection Pin 2 Of Amplifier B |
| 4 | G1B | Gain Selection Pin 1 Of Amplifier B |
| 5 | V- | Negative Power Supply |
| 6 | NC | No Connection |
| 7 | OUTPUT 2 | Output Pin 2 |
| 8 | OUTPUT 1 | Output Pin 1 |
| 9 | NC | No Connection |
| 10 | V+ | Positive Power Supply |
| 11 | G1A | Gain Selection Pin 1 Of Amplifier A |
| 12 | G2A | Gain Selection Pin 2 Of Amplifier A |
| 13 | NC | No Connection |
| 14 | IN 1 | Input Pin 1 Of Amplifier |
LM733 Features and Specification
- 120 MHz bandwidth
- 250 kX input resistance
- Selectable gains of 10, 100, 400
- No frequency compensation
- High common mode rejection ratio at high frequencies
Application
- Magnetic tape systems
- Disk file memories
- Thin and thick film memories
- Woven and plated wire memories
- Wide band video amplifiers
LM733 Datasheet
You can download this datasheet for LM733 Differential Amplifier from the link given below:
