The MJE350 is a silicon epitaxial planar PNP transistor intended for use in medium power linear and switching applications. It is mounted in SOT-32.The complementary NPN type is MJE340
MJE350 Pinout
MJE350 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Emitter |
| 2 | Collector |
| 3 | Base |
MJE350 Key Features
- High Collector–Emitter Sustaining Voltage — VCEO(sus) = 300 Vdc @ IC = 1.0 mAdc
- Excellent DC Current Gain — hFE = 30–240 @ IC = 50 mAdc
- Material of Transistor: Si
- Polarity: PNP
- Type Designator: MJE350
- Maximum Emitter-Base Voltage |Veb|: 3 V
MJE350 Specification
| Ic (mA) | Pd | Vce (max) | Vcb | hfe | @Ic | Ft |
|---|---|---|---|---|---|---|
| 0.5 | 20 | 300 | 300 | 30-240 | 50 | 10 |
MJE350 Equivalent/Alternate:
- MJE1101, MJE1102, MJE1103, MJE1123, MJE12007, MJE340
Application
- Low Power
- Line–Operated Series Pass
- Switching Regulators
- High Voltage
You can download this datasheet for MJE350 PNP Power Transistor from the link given below:
