IRFP150 42A 100V N-Channel Power MOSFETs from Vishay provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness. The TO-247AC package is preferred for commercial-industrial applications where higher power levels preclude the use of TO-220AB devices. The TO-247AC is similar but superior to the earlier TO-218 package because its isolated mounting hole. It also provides
greater creep age distances between pins to meet the requirements of most safety specifications.
IRFP150 Pinout
IRFP150 Pin Configuration
| Pin No | Pin Name |
|---|---|
| 1 | Gate |
| 2 | Drain |
| 3 | Source |
IRFP150 Key Features
- Advanced Process Technology
- Dynamic dv/dt Rating
- 175°C Operating Temperature
- Fast Switching
- Fully Avalanche Rated
- Type Designator: IRFP150
- Type of Transistor: MOSFET
- Type of Control Channel: N -Channel
IRFP150 Specification
| Id (A) | Pd (W) | Vds (max) | Rds (on) | Vgs (max) |
|---|---|---|---|---|
| 40 | 230 | 100 | 0.055 | 20 |
Type of Transistor:
- MOSFET
Type of Control Channel:
- N -Channel
Application
- Fast switching
- Fully Avalanche Rated
You can download this datasheet for IRFP150 42A 100V N-Channel Power MOSFET from the link given below:
